Öztiryakiler Glass Washer with Polisher Pump, 40x40 cm Basket

Öztiryakiler Glass Washer with Polisher Pump, 40x40 cm Basket

• Dishwasher Pump Type: With Polisher Pump
• Dishwasher Basket Size: 40x40 cm
• It is used to automatically draw polish from the bin.

• Body, boiler and wash tank made of stainless steel
• Hygienic washing tank
• Washing capacity of 30 baskets per hour (Basket dimensions 40cmx40cm)
• 5 liters of water consumption per wash cycle
• Automatic and user-friendly control panel
• Washing program period is 120 sec.
• Saves energy, detergent and water usage
• Washing arms are reinforced polypropylene(PP)
• Height optimization by adjustable feets
• Easy to start; filling with water and heating the boiler and washing tanks in one touch
• Electrical components and wiring systems meet international standards and safety
• The whole body is insulated and IPX5 protection against water.
• Rinsing and washing temperatures are thermostatically controlled for effective washing.
• Valve system that prevents the water in the machine from returning to the installation
• Washing water temperature 55-60°C (provided that the feed water is at least 2 bar and 50°C)
• Rinsing water temperature 80-85°C (provided that the feed water is at least 2 bar and 50°C)

Technicial Specifications

• Type: Electric
• Width (mm): 475
• Length (mm): 565
• Height (mm): 760
• Net Weight (Kg): 35(+/-5)
• Gross Weight (Kg): 40(+/-5)
• Volume (m3): 0.20
• Capacity: 500 Cups/Hour
• Electric Power: 3.3
• Volts: 230V - NPE
• Frequency: 50
• Hot Water Pressure: 2-4 bar
• Hot Water Hardness: 0-10 French Water Hardness
• Cold Water Inlet Diameter: 3/4''
• Cold Water Pressure: 2-4 bar
• Cold Water Hardness: 0-10 French Water Hardness
• Drainage Inlet Diameter: Ø 28
• Tank Volume: 18.4
• Boiler Volume: 2.8
• Boiler Heater Power: 3
• Tank Heater Power: 2
• Washing Pump Power: 0.27
• Rinse Pump Power: -
• Washing Water Temperature: 55 - 60
• Rinse Water Temperature: 80 - 85
• Drying Fan Power: -
• Maximum Noise: 70
